Manual Pipe Rotary Swaging Cone Tube End Taper Forming Machine for Furniture Legs Making
Low initial investment cost, no large capital occupation
Simple operation, workers can master it quickly without professional technical training
Low energy consumption, no complex hydraulic or electric control system, power cost saved
Low failure rate, few vulnerable parts, easy maintenance and low later maintenance cost
Convenient moving, light machine body, can shift production site at any time
Wide material adaptability, process iron pipe, steel pipe, stainless steel pipe, aluminum pipe and copper pipe
Integrated forming die design, quick mold replacement to switch different taper specifications
- Overview
- Recommended Products
Manual Metal Pipe Taper Machine Table Legs Making
| Machine Features: | ||
| 1.Easy to install,change mold and operate | ||
| 2.Easy to maintain and maintain cost is very low(the most waer out parts is mold,but its normally lifespan is 3 years) | ||
| 3.Wide working material (iron pipe,aluminum pipe,stainless steel,carbon steel,copper) and diameter(from 20mm-90mm) | ||
| 4.Requires no special location,compact design size,help you to save space | ||
| 5.Can be designed according to customer's reqirements. | ||
| Model | Max.Diameter | Max.Length | Max.Thickness | Feeding | Power | Dimensions | Weight |
| RG-M38350 | ø38mm | 350mm | 1.2mm | Manual | 4.2kW | 105x90x105cm | 1080kg |
| RG-M50400 | ø50mm | 400mm | 1.5mm | Manual | 5.7Kw | 90x110x105cm | 1200kg |
| RG-M76450 | ø76mm | 450mm | 2.0mm | Manual | 7.7Kw | 120x110x108cm | 1600kg |
| RG-M90600 | ø90mm | 800mm | 2.0mm | Manual | 11kw | 160x110x130cm | 3150kg |
* Manual Machine can be plus to semi-auto mode on freely.
Guangdong Rungoal Machinery Equipment Co., Ltd. (est. 1998, Foshan) is a long-standing manufacturer specializing in R&D and production of pipe deep-processing equipment. Holding numerous patents, we uniquely offers specialized furniture machine production lines in China such as manual/semi-automatic/fully automatic tube tapering machine,special-shaped pipe forming machine,pipe embossing machine,pipe end sealing/closing machine,pipe threading machine etc.For more than 20 years machine manufacture experience and 9 years export experience,our clients are from more than 70 contries and religions.Our machine offer 1 years warranty and free parts shipping,most of our machine working life exceed 5 years,customers are like using our equipment.
Q: Are you a manufacturer or trading company?
A:We have our own factory, Our company is based on the original factory and birth out the professional sales company.
Q: How to choose the pipe/tube embossing machines?
A:You have to inform us following details
A:Max. outside diameter
A:Wall thickness range
A:The pipe material
A:The drawings if possible
Q: MOQ of pipe embossing machine for decorative?
One set is ok.
Q: What kind of services can you give us?
A:1. Pre-sale can be targeted to give some constructive comments.
A:2. Develop a specific plan for your needs
A:3. After-sales reference to specific products, different with different service. Refer to the specific product description.
Q: Can you accept OEM/ODM ?
A:Our products can be customized design for our customer by OEM/ODM.
Q: What is the difference between you and other Chinese suppliers? What is the advantage?
A:1. We are sale enterprise, but we have our own factory. Products quality can be promise.
A:2. We can feedback the progress at any time, making you to stay at home will be able to clear in the heart.
A:3. If Conditions permitting, we can provide the appropriate services at any time.
